GEAR SHIFTING MECHANISM FOR DUCATI 916 SP 1995

GEAR SHIFTING MECHANISM for Ducati 916 SP 1995

(1)  77910391A
SCREW M8X21.5 (PACK OF 5)

(2)  45520181A
GEAR FIXING CLICK ASSEMBLY

(3)  85210532A
WASHER 8.2X20X1 (PACK OF 10)

(4)  79910491A
SPRING, RETURN (PACK OF 2)

(5)  768351134
BALL 11MM (PACK OF 10)

(6)  066013143
GEAR SELECTOR SPRING (PACK OF 10)

(7)  027291090
GASKET 16.2X24X2 (PACK OF 10)

(8)  77912033A
SCREW M16X1.5

(9)  180Z0031A
GEAR SELECTOR FORK,1ST/4TH-2ND/3RD

(9)  180Z0031A
GEAR SELECTOR FORK,1ST/4TH-2ND/3RD

(10)  82113881A
FORK PIN

(10)  82113881A
FORK PIN

(11)  85210051A
THRUST WASHER 1 MM (PACK OF 2)
(11)  85210061A
THRUST WASHER 0. 2MM
(11)  85210071A
THRUST WASHER 0.3 MM

(12)  53910072A
NEUTRAL LIGHT SWITCH

(13)  85211971A
GASKET, COPPER 8.5X14X2 (PACK OF 10)
(13)  050403085
GASKET 1.5 MM (PACK OF 10)
(13)  42020008A
COPPER GASKET 11X8.2X1 (PACK OF 10)

(14)  066013045
WARN. LIGHT CONTROL PIN (PACK OF 2)

(15)  066013057
NEEDLE RETAINING RING

(16)  066013050
SPECIAL ROLLER

(17)  18220062B
FORK DRUM

(18)  066013060
THRUST WASHER 45.2X49X1.0 (PACK OF 5)
(18)  066013061
THRUST WASHER 45.2X49X0.2 (PACK OF 5)
(18)  066013062
THRUST WASHER 45.2X49X0.3 (PACK OF 10)
(18)  85210941A
THRUST WASHER 45.2X49X0.9 (PACK OF 2)

(19)  180Z0041A
FORK-SHIFT, 5TH&6TH

(20)  18020261A
CONTROL FORK

(21)  79912961A
RETURN SPRING

(22)  82110011A
GEAR SELECTOR SHAFT

(23)  040009050
THRUST WASHER 10.5X16X0.5 (PACK OF 10)

(24)  88450341B
SPRING RING (PACK OF 10)

(25)  066013165
GEARCHANGE LEVER PIN

(26)  74810401A
NUT, FLANGE (PACK OF 20)

(27)  79915061A
SPRING, SHIFT RETURN

(28)  88110121A
CENTERING RING

(29)  85211721A
WASHER 6X14.2X1.3 (PACK OF 10)

(30)  77150678B
SCREW TCEI M6X16 (PACK OF 10)

(31)  77151238C
SCREW TCEI M8X20 (PACK OF 10)

(32)  85310021A
SPRING WASHER 8 MM (PACK OF 10)

(33)  82610261A
STOPPER PLATE

(34)  040029126
THRUST WASHER 15.5X22X0.5 (PACK OF 10)

(35)  735001542
CIRCLIP 15 DIN 471 (PACK OF 10)
Part number Description Unit Price Incl. Tax Qty
# 1

77910391A

SCREW M8X21.5 (PACK OF 5)
# 2

45520031A

45520181A
GEAR FIXING CLICK ASSEMBLY
# 3

85210531A

85210532A
WASHER 8.2X20X1 (PACK OF 10)
# 4

79910491A

SPRING, RETURN (PACK OF 2)
# 5

768351134

BALL 11MM (PACK OF 10)
# 6

066013143

GEAR SELECTOR SPRING (PACK OF 10)
# 7

027291090

GASKET 16.2X24X2 (PACK OF 10)
# 8

77912031A

77912033A
SCREW M16X1.5
# 9

18010011A

180Z0031A
GEAR SELECTOR FORK, 1ST/4TH-2ND/3RD
# 10

066013070

82113881A
FORK PIN
# 11

85210051A

THRUST WASHER 1 MM (PACK OF 2)
# 11

85210061A

THRUST WASHER 0. 2MM
Contact
# 11

85210071A

THRUST WASHER 0.3 MM
Contact
# 12

53910072A

NEUTRAL LIGHT SWITCH
# 13

015092280

85211971A
GASKET, COPPER 8.5X14X2 (PACK OF 10)
# 13

050403085

GASKET 1.5 MM (PACK OF 10)
# 13

42020008A

COPPER GASKET 11X8.2X1 (PACK OF 10)
# 14

066013045

WARN. LIGHT CONTROL PIN (PACK OF 2)
# 15

066013057

NEEDLE RETAINING RING
Contact
# 16

066013050

SPECIAL ROLLER
Contact
# 17

18220062B

FORK DRUM
Contact
# 18

066013060

THRUST WASHER 45.2X49X1.0 (PACK OF 5)
# 18

066013061

THRUST WASHER 45.2X49X0.2 (PACK OF 5)
# 18

066013062

THRUST WASHER 45.2X49X0.3 (PACK OF 10)
# 18

85210941A

THRUST WASHER 45.2X49X0.9 (PACK OF 2)
# 19

18010021A

180Z0041A
FORK-SHIFT, 5TH&6TH
# 20

18010081A

18020261A
CONTROL FORK
# 21

79910251A

79912961A
RETURN SPRING
# 22

82110011A

GEAR SELECTOR SHAFT
# 23

040009050

THRUST WASHER 10.5X16X0.5 (PACK OF 10)
# 24

021407350

88450341B
SPRING RING (PACK OF 10)
# 25

066013165

GEARCHANGE LEVER PIN
# 26

75050011A

74810401A
NUT, FLANGE (PACK OF 20)
# 27

079913110

79915061A
SPRING, SHIFT RETURN
# 28

88110121A

CENTERING RING
# 29

46230038A

85211721A
WASHER 6X14.2X1.3 (PACK OF 10)
# 30

60N102509

77150678B
SCREW TCEI M6X16 (PACK OF 10)
# 31

77151222B

77151238C
SCREW TCEI M8X20 (PACK OF 10)
# 32

46230037A

85310021A
SPRING WASHER 8 MM (PACK OF 10)
# 33

82610091A

82610261A
STOPPER PLATE
# 34

040029126

THRUST WASHER 15.5X22X0.5 (PACK OF 10)
# 35

735001542

CIRCLIP 15 DIN 471 (PACK OF 10)
Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Ducati. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the GEAR SHIFTING MECHANISM of your Ducati 916 SP of 1995. Let us know if you have any questions.

Ducati 916 SP 1995

Ducati 916 SP 1995

Superbike 1995 916 SP 916 SP
916 SP
Ducati Superbike
Year: 1995
Displacement: 916 cc
